B82141A1102K000
ActiveEPCOS - TDK Electronics
FIXED IND 1UH 725MA 190 MOHM TH
B82141A1102K000
ActiveEPCOS - TDK Electronics
FIXED IND 1UH 725MA 190 MOHM TH
Description
General part information
B82141A1102K000
1 µH Unshielded Drum Core, Wirewound Inductor 725 mA 190mOhm Max Axial
Technical Specifications
Parameters and characteristics for this part
| Specification | B82141A1102K000 |
|---|---|
| Current Rating | 725 mA |
| DC Resistance (DCR) (Max) | 190 mOhm |
| Frequency - Self Resonant | 180 MHz |
| Inductance | 1 µH |
| Inductance Frequency - Test | 7.96 MHz |
| Material - Core | Ferrite |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Q | 40 |
| Shielding | Unshielded |
| Size / Dimension Diameter | 0.118 in |
| Size / Dimension Length | 0.268 in |
| Tolerance | 10 % |
| Type | Drum Core, Wirewound |
