3061762
ActivePhoenix Contact
TERM BLK PLUG 2POS 8.2MM ORANGE
3061762
ActivePhoenix Contact
TERM BLK PLUG 2POS 8.2MM ORANGE
Description
General part information
3061762
2 Position Terminal Block Orange Plug Connection 8.2mm
Technical Specifications
Parameters and characteristics for this part
| Specification | 3061762 |
|---|---|
| Current - IEC | 41 A |
| Current - UL | 40 A |
| Height (Max) | 2.008 in |
| Housing Color | Orange |
| Length | 2.272 in |
| Material - Insulation | Polyamide, PA, Nylon |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | DIN Rail |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Stripping Length | 12 mm |
| Terminal Width | 8.2 mm |
| Termination Style | Push In, Plug Receptacles, Spring |
| Type | Plug Connection |
| Voltage - IEC | 1000 V |
| Voltage - UL | 600 V |
| Wire Gauge or Range - AWG (Max) | 20 AWG |
| Wire Gauge or Range - AWG (Min) | 8 AWG |
| Wire Gauge or Range - mm² (Maximum) | 10 mm² |
| Wire Gauge or Range - mm² (Minimum) | 0.5 mm² |
