1709449
ActivePhoenix Contact
PLUGGABLE TERMINAL BLOCKS PTSM 0,5/8-PL-2,5 BK
1709449
ActivePhoenix Contact
PLUGGABLE TERMINAL BLOCKS PTSM 0,5/8-PL-2,5 BK
Description
General part information
1709449
PLUGGABLE TERMINAL BLOCKS PTSM 0,5/8-PL-2,5 BK
Technical Specifications
Parameters and characteristics for this part
| Specification | 1709449 |
|---|---|
| Color | Black |
| Contact Mating Finish | Tin |
| Current - IEC | 6 A |
| Current - UL | 5 A |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Number of Positions | 8 |
| Operating Temperature (Max) | 100 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.098 in |
| Plug Wire Entry Angle | 180 ° |
| Positions Per Level | 8 |
| Termination Style | Screwless - Leg Spring, Push-In Spring |
| Type | Female Sockets, Plug |
| Voltage - IEC | 160 V |
| Voltage - UL | 150 V |
| Wire Gauge or Range - AWG (Max) | 25.5 AWG |
| Wire Gauge or Range - AWG (Min) | 18 AWG |
| Wire Gauge or Range - mm² (Maximum) | 0.5 mm² |
| Wire Gauge or Range - mm² (Minimum) | 0.14 mm² |
