SMC202LE G/W

Active

American Opto Plus LED

DISP 14SEG 0.2DUAL RED 20SMD

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

SMC202LE G/W

Active

American Opto Plus LED

DISP 14SEG 0.2DUAL RED 20SMD

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	SMC202LE G/W

Color	Red
Common Pin	Common Anode
Current - Test	20 mA
Digit/Alpha Size	5.08 mm
Digit/Alpha Size	0.2 in
Display Type	7-Segment
Millicandela Rating	12 mcd
Number of Characters	2
Package / Case	20-SMD, No Lead
Power Dissipation (Max) [Max]	70 mW
Size / Dimension [x]	0.394 "
Size / Dimension [x]	10 mm
Size / Dimension [y]	14.4 mm
Size / Dimension [y]	0.567 in
Size / Dimension [z]	0.118 "
Size / Dimension [z]	3 mm
Voltage - Forward (Vf) (Typ)	2 V
Wavelength - Peak	632 nm

SMC202 Series

DISP 14SEG 0.2DUAL RED 20SMD

Part	Millicandela Rating	Voltage - Forward (Vf) (Typ)	Wavelength - Peak	Color	Package / Case	Current - Test	Display Type	Digit/Alpha Size	Digit/Alpha Size	Common Pin	Number of Characters	Power Dissipation (Max) [Max]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]
American Opto Plus LED SMC202LE G/W	12 mcd	2 V	632 nm	Red	20-SMD, No Lead	20 mA	7-Segment	5.08 mm	0.2 in	Common Anode	2	70 mW	14.4 mm	0.394 "	0.118 "	3 mm	10 mm	0.567 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	1	$ 3.19
		10	$ 2.39
		100	$ 1.99
		500	$ 1.40
		750	$ 1.28

Description

General part information

SMC202 Series

Display Modules - LED Character and Numeric Red 7-Segment 2 Character Common Anode 2V 20mA 0.394" H x 0.567" W x 0.118" D (10.00mm x 14.40mm x 3.00mm) 20-SMD, No Lead

Documents

Technical documentation and resources
