MA250DMFMX-A-BOTTLE

Active

CONN ADPT.25TABS TO .25RCPT100PC

Search across all available documentation for this part.

Active

CONN ADPT.25TABS TO .25RCPT100PC

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	MA250DMFMX-A-BOTTLE	MA250DM Series

Contact Finish	Tin	Tin
Contact Material	Brass	Brass
Convert From (Adapter End)	Quick Connect, Male (2)	Quick Connect, Male (2)
Convert From (Adapter End)	6.35 mm	6.35 mm
Convert From (Adapter End)	0.25 in	0.25 in
Convert From (Adapter End)	0.25 in	0.25 in
Convert To (Adapter End)	0.25 in	0.25 in
Convert To (Adapter End)	Quick Connect, Female	Quick Connect, Female
Convert To (Adapter End)	6.35 mm	6.35 mm
Features	-	Side by Side Male Terminals, Stacked Terminals
Insulation	Non-Insulated	Non-Insulated

CONN ADPT.25TABS TO .25RCPT100PC

Part	Contact Material	Contact Finish	Convert From (Adapter End)	Convert From (Adapter End)	Convert From (Adapter End)	Convert From (Adapter End)	Insulation	Convert To (Adapter End)	Convert To (Adapter End)	Convert To (Adapter End)	Features
3M MA250DMFMX-A-BOTTLE	Brass	Tin	Quick Connect, Male (2)	6.35 mm	0.25 in	0.25 in	Non-Insulated	0.25 in	Quick Connect, Female	6.35 mm
3M MA250DMMFX-BOTTLE	Brass		Quick Connect, Male (2)	6.35 mm	0.25 in	0.25 in	Non-Insulated	0.25 in	Quick Connect, Female	6.35 mm	Side by Side Male Terminals
3M MA250DMFMK-A	Brass	Tin	Quick Connect, Male (2)	6.35 mm	0.25 in	0.25 in	Non-Insulated	0.25 in	Quick Connect, Female	6.35 mm
3M MA250DMFMK	Brass	Tin	Quick Connect, Male (2)	6.35 mm	0.25 in	0.25 in	Non-Insulated	0.25 in	Quick Connect, Female	6.35 mm	Stacked Terminals

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Terminal Adapter Connector 0.25" (6.35mm) 1/4" Quick Connect, Male (2) To 0.25" (6.35mm) 1/4" Quick Connect, Female

Technical documentation and resources
