Description
General part information
14031016101000
10 Position Wire to Board Terminal Block Vertical with Board 0.197" (5.00mm) Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 14031016101000 |
|---|---|
| Color | Green |
| Contact Material | Copper Alloy |
| Current | 12 A |
| Housing Material | Nylon, Polyamide, PA |
| Mating Orientation | Vertical with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Operating Temperature (Max) | 110 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.197 in |
| Plating | Tin Plated |
| Positions Per Level | 10 |
| Voltage | 600 V |
| Wire Gauge (AWG) (Max) | 30 AWG |
| Wire Gauge (AWG) (Min) | 12 AWG |
| Wire Termination | Leg Spring, Screwless, Push-In Spring |
