1221/15

Active

APM HEXSEAL

PUSHBUTTON FULL BOOT GRAY

Search across all available documentation for this part.

Active

APM HEXSEAL

PUSHBUTTON FULL BOOT GRAY

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	1221/15	1221 Series

Actuator Diameter [diameter]	0.375 "	0.32 - 0.375 "
Actuator Diameter [diameter]	9.53 mm	8.11 - 9.53 mm
Color	Gray	Gray
For Use With/Related Products	Multiple Series	Multiple Series
Ingress Protection	IP66/IP68	IP66/IP68
Material	Silicone Rubber	Silicone Rubber
Mounting Feature	Front of Panel	Front of Panel
Operating Temperature [Max]	204 °C	204 °C
Operating Temperature [Min]	-70 °C	-70 °C
Size / Dimension [z]	0.719 in	0.609 - 0.719 in
Size / Dimension [z]	18.26 mm	15.48 - 18.26 mm
Thread Size	15/32-32 NS-2B	15/32-32 NS-2B, 3/8-27 NS-2B
Type	Pushbutton, Full Boot	Pushbutton, Full Boot

PUSHBUTTON FULL BOOT GRAY

Part	Actuator Diameter [diameter]	Actuator Diameter [diameter]	Thread Size	Ingress Protection	Mounting Feature	For Use With/Related Products	Operating Temperature [Max]	Operating Temperature [Min]	Material	Size / Dimension [z]	Size / Dimension [z]	Color	Type
APM HEXSEAL 1221/15	0.375 "	9.53 mm	15/32-32 NS-2B	IP66/IP68	Front of Panel	Multiple Series	204 °C	-70 °C	Silicone Rubber	0.719 in	18.26 mm	Gray	Pushbutton, Full Boot
APM HEXSEAL 1221/12 29	0.32 in	8.11 mm	3/8-27 NS-2B	IP66/IP68	Front of Panel	Multiple Series	204 °C	-70 °C	Silicone Rubber	0.609 in	15.48 mm	Gray	Pushbutton, Full Boot

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

PUSHBUTTON FULL BOOT GRAY

Technical documentation and resources

No documents available
