M20057-EVB-1

Active

Antenova

M20057-1 EVALUATION BOARD

Search across all available documentation for this part.

Active

Antenova

M20057-1 EVALUATION BOARD

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	M20057-EVB-1	M20057 Series

Antenna Type	-	Chip
Applications	-	GNSS
Features	-	LNA
For Use With/Related Products	M20057-1	M20057-1
Frequency (Center/Band)	-	1.584 GHz
Frequency [Max]	1.609 GHz	1.609 GHz
Frequency [Min]	1.559 GHz	1.559 GHz
Frequency Group	-	2 GHz
Frequency Group	-	1 GHz
Frequency Group	-	UHF
Frequency Range	-	1.609 GHz
Frequency Range	-	1.559 GHz
Height (Max)	-	0.035 in
Height (Max)	-	0.9 mm
Mounting Type	-	Surface Mount
Number of Bands	-	1
RF Family/Standard	-	Navigation
Supplied Contents	Board(s)	Board(s)
Termination	-	Solder
Type	Antenna	Antenna

M20057-1 1559-1609 MHZ: GNSS SMD

Part	Mounting Type	Features	Antenna Type	Height (Max) [Max]	Height (Max) [Max]	Frequency (Center/Band)	Frequency Range [Max]	Frequency Range [Min]	RF Family/Standard	Termination	Applications	Number of Bands	Frequency Group [Max]	Frequency Group [Min]	Frequency Group	Supplied Contents	Type	For Use With/Related Products	Frequency [Max]	Frequency [Min]
Antenova M20057-1	Surface Mount	LNA	Chip	0.035 in	0.9 mm	1.584 GHz	1.609 GHz	1.559 GHz	Navigation	Solder	GNSS	1	2 GHz	1 GHz	UHF
Antenova M20057-EVB-1																Board(s)	Antenna	M20057-1	1.609 GHz	1.559 GHz

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 123.75

General part information

- M20057-1 Antenna 1.559GHz ~ 1.609GHz Evaluation Board
