5452451
LTBPhoenix Contact
TERM BLOCK HDR 18POS VERT 3.5MM
5452451
LTBPhoenix Contact
TERM BLOCK HDR 18POS VERT 3.5MM
Description
General part information
5452451
18 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.138" (3.50mm) Vertical Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 5452451 |
|---|---|
| Color | Black |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.138 in |
| Current - IEC | 8 A |
| Current - UL | 8 A |
| Features | Mating Flange |
| Header Orientation | Vertical |
| Insulation Height | 0.362 in |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 18 |
| Pitch | 0.138 in |
| Positions Per Level | 18 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - IEC | 160 V |
| Voltage - UL | 250 V |
