AS1301-9R

Active

Bel Power Solutions

DC/DC CONVERTER 12V 96W

Search across all available documentation for this part.

Active

Bel Power Solutions

DC/DC CONVERTER 12V 96W

Technical Specifications

Parameters and characteristics for this part

DC/DC CONVERTER 12V 96W

Part	Applications	Voltage - Input (Max) [Max] [custom]	Approval Agency	Voltage - Input (Min) [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Isolation	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Type	Current - Output (Max) [Max]	Mounting Type	Number of Outputs	Efficiency	Voltage - Output 1	Power (Watts)
Bel Power Solutions AS1301-9R	ITE (Commercial), Railway	35 V	cCSAus, CE, NEMKO	8 V	-40 °C	71 °C	2.8 kV	60 mm	110 mm	168.5 mm	2.36 in	6.63 "	4.33 "	Conformal Coated, Enclosed	8 A	Chassis Mount	1	81 %	12 V	96 W

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Enclosed, Conformal Coated DC DC Converter 1 Output 12V 8A 35V Input

Technical documentation and resources

No documents available
