Description
General part information
BOS00HY
Retroreflective Optical Sensor 52.49' (16m) NPN-NO
Technical Specifications
Parameters and characteristics for this part
| Specification | BOS00HY |
|---|---|
| Adjustment Angle | 270 ° |
| Adjustment Type | Potentiometer, Adjustable |
| Connection Method | Connector, M12 |
| Ingress Protection | IP67 |
| Light Source | Red |
| Light Source Wavelength (Red) | 650 nm |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | -10 °C |
| Output Configuration | NPN-NO |
| Sensing Distance | 52.49 ' |
| Sensing Method | Retroreflective |
| Voltage - Supply (Maximum) | 30 VDC |
| Voltage - Supply (Minimum) | 10 VDC |
