DESD5V0V1BDLP3-7
ObsoleteDiodes Inc
TVS DIODE 5VWM 12.8VC X2ESN06032
DESD5V0V1BDLP3-7
ObsoleteDiodes Inc
TVS DIODE 5VWM 12.8VC X2ESN06032
Description
General part information
DESD5V0V1BDLP3-7
This new generation TVS is designed to protect sensitive electronics from the damage due to ESD. The combination of small size and high ESD surge capability makes it ideal for use in portable applications such as cellular phones, digital cameras, and MP3 players.
Technical Specifications
Parameters and characteristics for this part
| Specification | DESD5V0V1BDLP3-7 |
|---|---|
| Applications | General Purpose |
| Bidirectional Channels | 1 |
| Capacitance | 5.3 pF |
| Current - Peak Pulse | 2 A |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -65 °C |
| Package / Case | 0201 (0603 Metric) |
| Package Name | X2-ESN0603-2 |
| Power - Peak Pulse | 20 W |
| Power Line Protection | No |
| Type | Zener |
| Voltage - Breakdown (Min) | 6 V |
| Voltage - Clamping (Max) | 12.8 V |
| Voltage - Reverse Standoff (Max) | 5 V |
