AE2.255KGC.00146
ObsoleteApacer Memory America
SSD 480GB 2.5" TLC SATA III 5V
AE2.255KGC.00146
ObsoleteApacer Memory America
SSD 480GB 2.5" TLC SATA III 5V
Description
General part information
AE2.255KGC.00146
Solid State Drive (SSD) FLASH - NAND (TLC) 480GB SATA III 2.5" 5V
Technical Specifications
Parameters and characteristics for this part
| Specification | AE2.255KGC.00146 |
|---|---|
| Current - Max | 320 mA |
| Form Factor Size | 2.5 in |
| Memory Size | 480 GB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (TLC) |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | 0 °C |
| Size / Dimension Height | 6.9 mm |
| Size / Dimension Length | 100 mm |
| Size / Dimension Width | 69.85 mm |
| Speed - Read | 560 MB/s |
| Speed - Write | 515 MB/s |
| Type | SATA III |
| Voltage - Supply | 5 VDC |
