| Accessory Type | - | Face Plate, Protective Boot, Combiner, Bracket, Relay, Diode Battery Isolator, Boot, Control, Disconnect Switch, Converter Plug, Plug Holder, Battery Isolator, Lever |
| Actuator Length | - | 9.53 - 38.1 mm |
| Actuator Marking | - | No Marking |
| Actuator Material | - | Brass, Nickel Plated, Plastic, Brass, Chrome Plated |
| Actuator Type | - | Standard Round, Concave (Curved), Flatted, Ball Tip |
| Applications | Industrial, Automotive | Industrial, Automotive |
| Backshell Material, Plating | - | Zinc Die Cast |
| Bushing Thread | - | 15/32-32 |
| Cable Opening | - | 0.735 in |
| Cable Opening | - | 18.66 mm |
| Cable Termination | - | Crimp |
| Circuit | - | DPDT, SPDT, SPST, SPST-NO, DPST |
| Coil Current | - | 1.4 - 685.7 A |
| Coil Resistance | - | 1.6 - 82 Ohms |
| Coil Type | - | Non Latching |
| Coil Voltage | - | 12 - 24 VDC |
| Color | Silver | Yellow, Black, Silver, Gray, Green, Multiple, Individual |
| Color - Actuator/Cap | - | Black |
| Connector Type | Female Sockets, Plug | Male Pins, Plug, Female Sockets, Receptacle, SAE Connector to SAE Connector |
| Contact Form | - | SPST-NO (1 Form A), SPDT (1 Form C), DPST-NO (2 Form A), DPDT (2 Form C) |
| Contact Material | Brass | Copper, Brass, Silver (Ag) |
| Contact Rating (Current) | - | 50 - 750 A |
| Current Rating (Amps) | 20 A | 10 - 75 A |
| Fastening Type | Push-Pull | Push-Pull |
| Features | Cable Clamp, Strain Relief | Strain Relief, Backshell, Cap (Cover), Cable Clamp, Polarity Reversing |
| For Use With/Related Products | - | Disconnect Switch, Vehicle Connectors, Batteries, Battery Isolator, 12V Battery |
| Illumination | - | Non-Illuminated, Illuminated |
| Illumination Type, Color | - | Incandescent, Red/White |
| Illumination Voltage (Nominal) | - | 12 VDC |
| Insert Material | - | Thermoplastic, Glass Filled, Thermoplastic |
| Length | - | 152.4 mm |
| Length | - | 6 " |
| Length | - | 0.5 ' |
| Load Current | - | 85 A |
| Material | - | Rubber, Thermoplastic, Glass Filled |
| Mounting Feature | - | Flange |
| Mounting Type | Free Hanging (In-Line) | Panel Mount, Snap-In, Free Hanging (In-Line), Chassis Mount |
| Must Operate Voltage | - | 7.8 VDC |
| Number of Positions | 4 | 2 - 13 |
| Number of Positions | - | 1 |
| Number of Positions | - | 6 |
| Number of Rows | - | 1 |
| Operating Temperature | - | 60 - 85 °C |
| Operating Temperature | - | -40 °C |
| Orientation | Keyed | N, Keyed |
| Output Type | - | DC |
| Package / Case | - | SSR with Integrated Heat Sink |
| Panel Cutout Dimensions | - | 11.9 mm |
| Panel Cutout Dimensions | - | 13.97 mm |
| Panel Cutout Dimensions | - | 28.57 mm |
| Primary Material | Metal | Plastic, Metal |
| Relay Type | - | General Purpose |
| Seal Rating | - | Sealed - Fully |
| Shell Material | Zinc Die Cast | Thermoplastic, Glass Filled, Zinc Die Cast, Zinc, Steel |
| Shielding | Unshielded | Unshielded |
| Switch Function | - | Mom-Off-On, On-On, On-Off, On-Off-On, Mom-Off-Mom, On-On-Off, Off-Mom, Mom-On-Off |
| Termination | Screw | Solder, Screw, Solder Tabs |
| Termination Style | - | Quick Connect - 0.250" (6.3mm), Screw Terminal, Wire Leads, Stud |
| Voltage - Input | - | 31 VDC |
| Voltage - Input | - | 9 VDC |
| Voltage Rating | - | 12 - 24 VDC |
| Voltage Rating - AC | - | 125 V |
| Voltage Rating - DC | - | 12 - 24 V |
