Description
General part information
RSF500JT-91-680R
680 Ohms ±5% 5W Through Hole Resistor Axial Flame Proof, Safety Metal Oxide Film
Technical Specifications
Parameters and characteristics for this part
| Specification | RSF500JT-91-680R |
|---|---|
| Composition | Metal Oxide Film |
| Features | Safety, Flame Proof |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 235 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Package Name | Axial |
| Power (Watts) | 5 W |
| Resistance | 680 Ohm |
| Size / Dimension Diameter | 0.335 in |
| Size / Dimension Length | 0.965 in |
| Temperature Coefficient | 300 ppm/°C |
| Tolerance | 5 % |
