Description
General part information
C4ASWBU2470A3AJ
0.047 µF Film Capacitor 700V 2000V (2kV) Polypropylene (PP), Metallized Radial
Technical Specifications
Parameters and characteristics for this part
| Specification | C4ASWBU2470A3AJ |
|---|---|
| Applications | Snubber, DC Filtering, DC Link |
| Capacitance | 47 nF |
| Dielectric Material | Metallized, Polypropylene (PP) |
| ESR (Equivalent Series Resistance) | 27.9 mOhm |
| Height - Seated (Max) | 0.787 in |
| Lead Spacing | 1.083 in |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Radial |
| Size / Dimension Length | 1.26 in |
| Size / Dimension Width | 0.394 in |
| Termination | PC Pins |
| Tolerance | 5 % |
| Voltage Rating - AC | 700 V |
| Voltage Rating - DC | 2 kVDC |
