8445 060500

Active

Belden Inc.

CABLE 5COND 22AWG CHROME

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 5COND 22AWG CHROME

Technical Specifications

Parameters and characteristics for this part

Specification	8445 060500

Cable Type	Multi-Conductor
Conductor Insulation	Poly-Vinyl Chloride (PVC)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	7
Conductor Strand [custom]	30 AWG
Jacket (Insulation) Diameter [diameter]	0.194 in
Jacket (Insulation) Diameter [diameter]	4.93 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket Color	Chrome
Length [x]	500 '
Length [x]	152.4 m
Number of Conductors	5
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-20 C
Ratings	UL Style 2576
Usage	Audio, Instrumentation, Control
Wire Gauge	22 AWG

Part	Conductor Insulation	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Number of Conductors	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Strand [custom]	Conductor Strand [custom]	Jacket Color	Usage	Length [x]	Length [x]	Cable Type	Wire Gauge	Conductor Material	Jacket (Insulation) Material	Ratings
Belden Inc. 8445 060100	Poly-Vinyl Chloride (PVC)	0.194 in	4.93 mm	5	-20 C	80 C	7	30 AWG	Chrome	Audio Control Instrumentation	30.5 m	100 ft	Multi-Conductor	22 AWG	Copper Tinned	Poly-Vinyl Chloride (PVC)
Belden Inc. 8445 060500	Poly-Vinyl Chloride (PVC)	0.194 in	4.93 mm	5	-20 C	80 C	7	30 AWG	Chrome	Audio Control Instrumentation	152.4 m	500 '	Multi-Conductor	22 AWG	Copper Tinned	Poly-Vinyl Chloride (PVC)	UL Style 2576

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

5 Conductor Multi-Conductor Cable Chrome 22 AWG 500.0' (152.4m)
