Technical Specifications
Parameters and characteristics for this part
| Specification | CF140-15-12-UL |
|---|---|
| Cable Type | Multi-Conductor |
| Conductor Insulation | Thermoplastic Elastomer (TPE) |
| Conductor Material | Copper, Bare |
| Features | Rip Cord, Flame Retardant |
| Jacket (Insulation) Diameter [diameter] | 0.63 in |
| Jacket (Insulation) Diameter [diameter] | 16 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket Color | Gray |
| Length | Enter Number of Feet in Order Quantity |
| Number of Conductors | 12 |
| Ratings | UL Style 20200 |
| Shield Coverage | 80 % |
| Shield Material | Copper, Tinned |
| Shield Type | Braid |
| Usage | Industrial, Control |
| Voltage | 300 V |
| Wire Gauge | 16 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 6.08 | |
| 100 | $ 5.84 | |||
| 500 | $ 5.61 | |||
| 1000 | $ 4.90 | |||
Description
General part information
CF140-15-12-UL
12 Conductor Multi-Conductor Cable Gray 16 AWG Braid Enter Number of Feet in Order Quantity
