PCHC63R8-R82M-RC
ActiveAllied Components International
.82UH +/-20% PWR CHOKE HI-CURR.
PCHC63R8-R82M-RC
ActiveAllied Components International
.82UH +/-20% PWR CHOKE HI-CURR.
Description
General part information
PCHC63R8-R82M-RC
820 nH Shielded Inductor 14 A 6mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | PCHC63R8-R82M-RC |
|---|---|
| Current - Saturation (Isat) | 16 A |
| Current Rating | 14 A |
| DC Resistance (DCR) (Max) | 6 mOhm |
| Height - Seated (Max) | 0.118 in |
| Inductance | 820 nH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.287 in |
| Size / Dimension Width | 0.26 in |
| Tolerance | 20 % |
