FFSD-10 Series

Ribbon Cables / IDC Cables .050" Low Profile Tiger Eye IDC Ribbon Cable Assembly

...

Part	Pitch - Connector	Color	Features	Contact Finish	Number of Positions	Contact Finish Thickness	Length	Connector Type	Number of Rows	Pitch - Cable	Shielding	Cable Termination
Samtec Inc. FFSD-10-D-30.00-01-N-R	0.05 in	Gray Ribbon	Polarizing Key	Gold	20	10 Ąin	2.5 ft	Reversed Socket to Socket	2	0.025 in	Unshielded	IDC
Samtec Inc. FFSD-10-D-10.45-01-N	0.05 in	Gray Ribbon	Polarizing Key	Gold	20	10 Ąin	0.871 ft	Socket to Socket	2	0.025 in	Unshielded	IDC
Samtec Inc. FFSD-10-S-05.00-01-N-RW	0.05 in	Gray Ribbon	Polarizing Key Reverse Wiring	Gold	20	10 Ąin	0.417 ft	Socket to Cable	2	0.025 in	Unshielded	IDC
Samtec Inc. FFSD-10-D-50.00-01-N-R	0.05 in	Gray Ribbon	Polarizing Key Reverse Wiring	Gold	20	10 Ąin	4.17 ft	Reversed Socket to Socket	2	0.025 in	Unshielded	IDC
Samtec Inc. FFSD-10-S-12.00-01-S-N	0.05 in	Gray Ribbon	Polarizing Key	Gold	20	30 µin	12 in	Socket to Cable	2	0.025 in	Unshielded	IDC
Samtec Inc. FFSD-10-D-55.00-01-N	0.05 in	Gray Ribbon	Polarizing Key	Gold	20	10 Ąin	4.58 ft	Socket to Socket	2	0.025 in	Unshielded	IDC
Samtec Inc. FFSD-10-S-02.00-01-F-N	0.05 in	Gray Ribbon	Polarizing Key	Gold	20	3 µin	2.004 in	Socket to Cable	2	0.025 in	Unshielded	IDC
Samtec Inc. FFSD-10-D-07.88-01-N	0.05 in	Gray Ribbon	Polarizing Key	Gold	20	10 Ąin	0.657 ft	Socket to Socket	2	0.025 in	Unshielded	IDC
Samtec Inc. FFSD-10-D-01.50-01-F-N	0.05 in	Gray Ribbon	Polarizing Key	Gold	20	3 µin	1.5 in	Socket to Socket	2	0.025 in	Unshielded	IDC
Samtec Inc. FFSD-10-D-20.00-01-F-N	0.05 in	Gray Ribbon	Polarizing Key	Gold	20	3 µin	1.67 ft	Socket to Socket	2	0.025 in	Unshielded	IDC

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources
