DCM251515H-393HF
ActiveITG Electronics, Inc.
39,000UH,1100MOHM,0.8AMP DIP CMC
DCM251515H-393HF
ActiveITG Electronics, Inc.
39,000UH,1100MOHM,0.8AMP DIP CMC
Description
General part information
DCM251515H-393HF
39 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 800mA DCR 1.1Ohm
Technical Specifications
Parameters and characteristics for this part
| Specification | DCM251515H-393HF |
|---|---|
| Current Rating (Max) | 800 mA |
| DC Resistance (DCR) (Max) | 1.1 Ohm |
| Filter Type | Power Line |
| Height (Max) | 0.551 in |
| Inductance | 39 mH |
| Mounting Type | Through Hole |
| Number of Lines | 2 |
| Operating Temperature (Max) | 130 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 4 PC Pin, Horizontal |
| Package Leads | 4 Leads |
| Package Name | Horizontal |
| Size / Dimension Length | 0.965 in |
| Size / Dimension Width | 0.61 in |
