SM1608A-1R2MHF
ActiveITG Electronics, Inc.
MOLDED INDUCTOR 1.2UH 23M 7A
SM1608A-1R2MHF
ActiveITG Electronics, Inc.
MOLDED INDUCTOR 1.2UH 23M 7A
Description
General part information
SM1608A-1R2MHF
1.2 µH Shielded Molded Inductor 6 A 26.5mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | SM1608A-1R2MHF |
|---|---|
| Current - Saturation (Isat) | 7 A |
| Current Rating | 6 A |
| DC Resistance (DCR) (Max) | 26.5 mOhm |
| Height - Seated (Max) | 0.236 in |
| Inductance | 1.2 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Metal |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.173 in |
| Size / Dimension Width | 0.165 in |
| Tolerance | 20 % |
| Type | Molded |
