RLF7030T-3R3M4R1
ObsoleteTDK Corporation
POWER INDUCTOR (SMD), 3.3 ΜH, 4.1 A, SHIELDED, 4.4 A, RLF SERIES
RLF7030T-3R3M4R1
ObsoleteTDK Corporation
POWER INDUCTOR (SMD), 3.3 ΜH, 4.1 A, SHIELDED, 4.4 A, RLF SERIES
Description
General part information
RLF7030T-3R3M4R1
3.3 µH Shielded Drum Core, Wirewound Inductor 4.1 A 20.88mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | RLF7030T-3R3M4R1 |
|---|---|
| Current - Saturation (Isat) | 4.4 A |
| Current Rating | 4.1 A |
| DC Resistance (DCR) (Max) | 20.88 mOhm |
| Height - Seated (Max) | 0.126 in |
| Inductance | 3.3 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.287 in |
| Size / Dimension Width | 0.268 in |
| Tolerance | 20 % |
| Type | Drum Core, Wirewound |
