1763672
ActivePhoenix Contact
TERM BLOCK HDR 20POS VERT 3.81MM
1763672
ActivePhoenix Contact
TERM BLOCK HDR 20POS VERT 3.81MM
Description
General part information
1763672
20 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.150" (3.81mm) Vertical Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 1763672 |
|---|---|
| Color | Green |
| Contact Mating Finish | Tin |
| Current - IEC | 8 A |
| Features | Mating and Mounting Flange |
| Header Orientation | Vertical |
| Insulation Height | 0.362 in |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 20 |
| Pitch | 0.15 in |
| Positions Per Level | 20 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - IEC | 160 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
