DC0022/03-TG-A482K-0.1-0

Active

t-Global Technology

THERM PAD 63.5X50.8MM RED

Search across all available documentation for this part.

Active

t-Global Technology

THERM PAD 63.5X50.8MM RED

Technical Specifications

Parameters and characteristics commom to parts in this series

THERM PAD 63.5X50.8MM RED

Part	Usage	Thickness	Thickness	Color	Thermal Conductivity	Shelf Life	Shape	Material	Shelf Life Start	Outline [y]	Outline [x]	Type	Adhesive	Thickness [x]	Thickness [x]	Backing, Carrier	Thickness [custom]	Thickness [custom]
t-Global Technology DC0022/03-TG-A482K-0.1-0	Power Module	0.1 mm	0.0039 in	Red	2.3 W/m-K	24 Months	Rectangular	Silicone	Date of Purchase	50.8 mm	63.5 mm	Die-Cut Pad, Sheet
t-Global Technology DC0022/03-TI900-0.12-2A	Power Module			White	1.8 W/m-K	24 Months	Rectangular	Silicone		50.8 mm	63.5 mm	Die-Cut Pad, Sheet	Adhesive - Both Sides	0.005 in	0.127 mm	Viscose
t-Global Technology DC0022/03-TG-A486G-0.3-2A	Power Module			Gray	6 W/m-K	12 Months	Rectangular		Date of Purchase	50.8 mm	63.5 mm	Die-Cut Pad, Sheet	Adhesive - Both Sides				0.305 mm	0.012 "
t-Global Technology DC0022/03-TG-A373F-0.25-2A	Power Module			Yellow	1.4 W/m-K	12 Months	Rectangular			50.8 mm	63.5 mm	Die-Cut Pad, Sheet	Adhesive - Both Sides				0.254 mm	0.01 in
