Description
General part information
TWW15J470E
470 Ohms ±5% 15W Through Hole Resistor Radial Flame Proof, Safety Wirewound
Technical Specifications
Parameters and characteristics for this part
| Specification | TWW15J470E |
|---|---|
| Composition | Wirewound |
| Features | Safety, Flame Proof |
| Height - Seated (Max) | 1.535 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 275 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial |
| Package Name | Radial |
| Power (Watts) | 15 W |
| Resistance | 470 Ohm |
| Size / Dimension Length | 0.787 in |
| Size / Dimension Width | 0.512 in |
| Temperature Coefficient | 350 ppm/°C |
| Tolerance | 5 % |
