General part information
Headers & Wire Housings USS00411370SCT STRIP CON
Technical documentation and resources
Parameters and characteristics for this part
| Specification | 0033.4011 |
|---|---|
| Approval Agency | UR, SEMKO, CSA |
| Circuit | SP3T |
| Current Rating (Amps) | 10 A |
| Depth Behind Flange [z] | 21 mm |
| Features | 220-230-240 |
| Illumination | Non-Illuminated |
| Ingress Protection | IP40 |
| Mechanical Life | 300 Cycles |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Panel Cutout Dimensions [diameter] | 14.1 mm |
| Switch Function | On-On-On |
| Termination Style | Solder Lug |
| Type | Line Voltage Selector |
| Voltage Rating - AC | 250 V |
Headers & Wire Housings USS00411370SCT STRIP CON
| Part | Switch Function | Approval Agency | Illumination | Type | Features | Current Rating (Amps) | Termination Style | Mechanical Life | Circuit | Operating Temperature [Max] | Operating Temperature [Min] | Panel Cutout Dimensions [diameter] | Depth Behind Flange [z] | Voltage Rating - AC | Ingress Protection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SCHURTER Inc. 0033.4011 | On-On-On | CSA, SEMKO, UR | Non-Illuminated | Line Voltage Selector | 220-230-240 | 10 A | Solder Lug | 300 Cycles | SP3T | 85 °C | -40 °C | 14.1 mm | 21 mm | 250 V | IP40 |
