TS2C3M20C

Active

Switchcraft Inc.

CONN PLUG MALE 3POS GOLD CRIMP

Search across all available documentation for this part.

Active

Switchcraft Inc.

CONN PLUG MALE 3POS GOLD CRIMP

Technical Specifications

Parameters and characteristics for this part

Specification	TS2C3M20C

Applications	Audio, Testing Equipment & Measurement, Agriculture, Medical, General
Backshell Material, Plating	Copper Alloy, Nickel
Cable Opening [Max] [diameter]	5.49 mm
Cable Opening [Max] [diameter]	0.216 in
Cable Opening [Min] [diameter]	4.57 mm
Cable Opening [Min] [diameter]	0.18 in
Color	Silver
Connector Type	Plug, Male Pins
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Features	Coupling Nut, Backshell
Ingress Protection	IP68, IP66, IP67
Insert Material	Liquid Crystal Polymer (LCP)
Mounting Type	Free Hanging (In-Line)
Operating Temperature [Max]	135 °C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Metal
Shell Finish	Electroless Nickel
Shell Material	Copper Alloy
Shielding	Shielded
Termination	Crimp, Solder Cup
Voltage Rating	125 VAC

CONN PLUG MALE 3POS GOLD CRIMP

Part	Insert Material	Shielding	Cable Opening [Max] [diameter]	Cable Opening [Min] [diameter]	Cable Opening [Min] [diameter]	Cable Opening [Max] [diameter]	Operating Temperature [Max]	Operating Temperature [Min]	Features	Orientation	Connector Type	Color	Ingress Protection	Mounting Type	Primary Material	Applications	Contact Material	Backshell Material, Plating	Shell Material	Contact Finish - Mating	Shell Finish	Termination	Voltage Rating
Switchcraft Inc. TS2C3M20C	Liquid Crystal Polymer (LCP)	Shielded	5.49 mm	4.57 mm	0.18 in	0.216 in	135 °C	-40 °C	Backshell, Coupling Nut	Keyed	Male Pins, Plug	Silver	IP66, IP67, IP68	Free Hanging (In-Line)	Metal	Agriculture, Audio, General, Medical, Testing Equipment & Measurement	Copper Alloy	Copper Alloy, Nickel	Copper Alloy	Gold	Electroless Nickel	Crimp, Solder Cup	125 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Position Circular Connector Plug, Male Pins Crimp or Solder Cup
