DCW05C-05
ObsoleteMEAN WELL USA Inc.
DC DC CONVERTER +/-5V 5W
DCW05C-05
ObsoleteMEAN WELL USA Inc.
DC DC CONVERTER +/-5V 5W
Description
General part information
DCW05C-05
Isolated Module DC DC Converter 2 Output 5V -5V 500mA, 500mA 36V - 72V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | DCW05C-05 |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) | 500 mA |
| Efficiency | 77 % |
| Features | SCP, OCP |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature (Max) | 71 °C |
| Operating Temperature (Min) | -40 °C |
| Package Leads | 8 Leads |
| Package Name | 24-DIP Module |
| Power (Watts) | 5 W |
| Size / Dimension Height | 0.48 in |
| Size / Dimension Length | 1.25 in |
| Size / Dimension Width | 0.8 in |
| Type | Isolated Module |
| Voltage - Input (Max) | 72 V |
| Voltage - Input (Min) | 36 V |
| Voltage - Isolation | 1000 Vrms |
| Voltage - Output 1 | 5 V |
| Voltage - Output 2 | -5 V |
