Description
General part information
A958AL112M800S
1100 µF (EDLC) Supercapacitor 800 V Module 125mOhm 9000 Hrs @ 105°C
Technical Specifications
Parameters and characteristics for this part
| Specification | A958AL112M800S |
|---|---|
| Capacitance | 1100 µF |
| ESR (Equivalent Series Resistance) | 125 mOhm |
| Height - Seated (Max) | 3.803 in |
| Lifetime | 9000 Hrs |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Module |
| Size / Dimension Length | 5.567 in |
| Size / Dimension Width | 4.331 in |
| Termination | Screw Terminals |
| Tolerance | 20 % |
| Voltage - Rated | 800 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
