PC0705-180K-RC
ActiveAllied Components International
18UH +/-10% POWER CHIP INDUCTOR
PC0705-180K-RC
ActiveAllied Components International
18UH +/-10% POWER CHIP INDUCTOR
Description
General part information
PC0705-180K-RC
18 µH Unshielded Wirewound Inductor 1.6 A 100mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | PC0705-180K-RC |
|---|---|
| Current Rating | 1.6 A |
| DC Resistance (DCR) (Max) | 100 mOhm |
| Height - Seated (Max) | 0.209 in |
| Inductance | 18 µH |
| Inductance Frequency - Test | 2.52 MHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Unshielded |
| Size / Dimension Length | 0.307 in |
| Size / Dimension Width | 0.276 in |
| Tolerance | 20 % |
| Type | Wirewound |
