Specification	PC95PQ35/35Z-12

Core Factor (ΣI/A) mm⁻¹	0.45 mm⁻¹
Core Type	PQ
Effective Area (Ae)	196 mm²
Effective Length (le)	87.9 mm
Effective Magnetic Volume (Ve)	17300 mm³
Finish	Uncoated
Gap	Ungapped
Height	1.368 in
Inductance Factor (Al)	7.32 µH
Length	1.382 in
Material	PC95
Package Length	35 mm
Package Name	PQ
Package Width	35 mm
Tolerance	25 %
Width	1.024 in
