74LX1G04BJR
ActiveSTMicroelectronics
IC INVERTER 1CH 1-INP 4FLIPCHIP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
74LX1G04BJR
ActiveSTMicroelectronics
IC INVERTER 1CH 1-INP 4FLIPCHIP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 74LX1G04BJR |
|---|---|
| Current - Output High, Low [x] | 32 mA |
| Current - Output High, Low [y] | 32 mA |
| Current - Quiescent (Max) [Max] | 10 µA |
| Logic Type | Inverter |
| Max Propagation Delay @ V, Max CL | 4.2 ns |
| Mounting Type | Surface Mount |
| Number of Circuits | 1 |
| Number of Inputs | 1 |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | 4-WFBGA, FCBGA |
| Supplier Device Package | 4-FlipChip (1.07x1.07) |
| Voltage - Supply [Max] | 5.5 V |
| Voltage - Supply [Min] | 1.65 V |
