General part information
"UMT-H, 5 A, 277 VAC, 125 VDC, TIME-LAG T, 1.500 PCS., FUSE, , SMT, 0X0 MM\/
Technical documentation and resources
Parameters and characteristics for this part
| Specification | 3403.0280.23 |
|---|---|
| Approval Agency | CQC, VDE, cURus |
| Breaking Capacity @ Rated Voltage | 1.5 kA |
| Current Rating (Amps) | 4 A |
| Fuse Type | Board Mount |
| Melting I˛t | 48 |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | 2-SMD, Square End Block |
| Response Time | Slow Blow |
| Size / Dimension [x] | 0.606 " |
| Size / Dimension [x] | 15.4 mm |
| Size / Dimension [y] | 5.35 mm |
| Size / Dimension [y] | 0.211 " |
| Size / Dimension [z] | 0.211 in |
| Size / Dimension [z] | 5.35 mm |
| Voltage Rating - AC | 277 V |
| Voltage Rating - DC | 125 VDC |
"UMT-H, 5 A, 277 VAC, 125 VDC, TIME-LAG T, 1.500 PCS., FUSE, , SMT, 0X0 MM\/
| Part | Current Rating (Amps) | Breaking Capacity @ Rated Voltage | Voltage Rating - AC | Approval Agency | Melting I˛t | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Fuse Type | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Voltage Rating - DC | Package / Case | Response Time |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SCHURTER Inc. 3403.0280.23 | 4 A | 1.5 kA | 277 V | CQC, cURus, VDE | 48 | Surface Mount | -55 °C | 125 °C | Board Mount | 5.35 mm | 0.606 " | 15.4 mm | 0.211 in | 0.211 " | 5.35 mm | 125 VDC | 2-SMD, Square End Block | Slow Blow |
