G4015M24B-RSR-CC

Active

Mechatronics Fan Group

FAN AXIAL 40X15MM 24VDC WIRE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet DC Lead Wire Specs +1

G4015M24B-RSR-CC

Active

Mechatronics Fan Group

FAN AXIAL 40X15MM 24VDC WIRE

Deep-Dive with AI

DocumentsDatasheet DC Lead Wire Specs +1

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 14.35
		10	$ 13.70
		25	$ 12.88
		50	$ 12.39
		100	$ 11.42
		250	$ 10.68
		500	$ 10.52

Description

General part information

G4015 Series

Fan Tubeaxial 24VDC Square - 40mm L x 40mm H Ball 6.0 CFM (0.168m³/min) 2 Wire Leads

Documents

Technical documentation and resources

Datasheet

DC Lead Wire Specs

AC/DC Fans & Blowers Catalog

Datasheet

Specification	G4015M24B-RSR-CC	G4015 Series

Air Flow	6 CFM	4 - 12 CFM
Air Flow	0.168 m³/min	0.112 - 0.336 mł/min
Approval Agency	CE, cUL, TUV, UL	CE, cUL, TUV, UL
Bearing Type	Ball	Ball
Current Rating (Amps)	70 mA	0.09 - 400 mA
Fan Type	Tubeaxial	Tubeaxial
Features	Thermal Overload Protector (TOP), Conformal Coating	Thermal Overload Protector (TOP), Locked Rotor Sensor, Speed Sensor (Tach), Conformal Coating
Material - Blade	Polybutylene Terephthalate (PBT)	Polybutylene Terephthalate (PBT)
Noise	23 dB(A)	20 - 39 dB(A)
RPM	6000 RPM	4000 - 12000 RPM
Size / Dimension	Square	Square
Size / Dimension [x]	40 mm	40 mm
Size / Dimension [z]	40 mm	40 mm
Static Pressure	-	17.4 - 149.5 Pa
Static Pressure	-	0.07 - 0.6 in H2O
Termination	2 Wire Leads	2 Wire Leads, 3 Wire Leads
Voltage - Rated	24 VDC	5 - 24 V
Weight	23.13 g	23.13 g
Weight	0.051 lb	0.051 lb
Width [x]	15 mm	15 mm

Part

Width [x]

Features

Termination

Approval Agency

Fan Type

Noise

Weight

Material - Blade

Static Pressure

Current Rating (Amps)

Air Flow

Size / Dimension [z]

Size / Dimension

Size / Dimension [x]

Voltage - Rated

RPM

Bearing Type

Mechatronics Fan Group

G4015H05B-RSR

15 mm

Thermal Overload Protector (TOP)

2 Wire Leads

CE, cUL, TUV, UL

Tubeaxial

29 dB(A)

23.13 g

0.051 lb

Polybutylene Terephthalate (PBT)

72.2 Pa

0.29 in H2O

400 mA

0.224 mł/min

8 CFM

40 mm

Square

40 mm

5 V

8000 RPM

Ball

Mechatronics Fan Group

G4015X12B-RSR

15 mm

Thermal Overload Protector (TOP)

2 Wire Leads

CE, cUL, TUV, UL

Tubeaxial

39 dB(A)

23.13 g

0.051 lb

Polybutylene Terephthalate (PBT)

149.5 Pa

0.6 in H2O

0.35 A

0.336 mł/min

12 CFM

40 mm

Square

40 mm

12 VDC

12000 RPM

Ball

Mechatronics Fan Group

G4015L24B-RSR

15 mm

Thermal Overload Protector (TOP)

2 Wire Leads

CE, cUL, TUV, UL

Tubeaxial

20 dB

23.13 g

0.051 lb

Polybutylene Terephthalate (PBT)

17.4 Pa

0.07 in H2O

50 mA

0.112 m³/min

4 CFM

40 mm

Square

40 mm

24 VDC

4000 RPM

Ball

Mechatronics Fan Group

G4015H24B-RSR

15 mm

Thermal Overload Protector (TOP)

2 Wire Leads

CE, cUL, TUV, UL

Tubeaxial

29 dB(A)

23.13 g

0.051 lb

Polybutylene Terephthalate (PBT)

72.2 Pa

0.29 in H2O

0.09 A

0.224 mł/min

8 CFM

40 mm

Square

40 mm

24 VDC

8000 RPM

Ball

Mechatronics Fan Group

G4015E24B-RSR

15 mm

Thermal Overload Protector (TOP)

2 Wire Leads

CE, cUL, TUV, UL

Tubeaxial

35 dB

23.13 g

0.051 lb

Polybutylene Terephthalate (PBT)

107.1 Pa

0.43 in H2O

110 mA

40 mm

Square

40 mm

24 VDC

10000 RPM

Ball

Mechatronics Fan Group

G4015E12B-RSR

15 mm

Thermal Overload Protector (TOP)

2 Wire Leads

CE, cUL, TUV, UL

Tubeaxial

35 dB

23.13 g

0.051 lb

Polybutylene Terephthalate (PBT)

107.1 Pa

0.43 in H2O

270 mA

0.28 mł/min

10 CFM

40 mm

Square

40 mm

12 VDC

10000 RPM

Ball

Mechatronics Fan Group

G4015X24B-RSR

15 mm

Thermal Overload Protector (TOP)

2 Wire Leads

CE, cUL, TUV, UL

Tubeaxial

39 dB(A)

23.13 g

0.051 lb

Polybutylene Terephthalate (PBT)

149.5 Pa

0.6 in H2O

0.336 mł/min

12 CFM

40 mm

Square

40 mm

24 VDC

12000 RPM

Ball

Mechatronics Fan Group

G4015M12B-RSR

15 mm

Thermal Overload Protector (TOP)

2 Wire Leads

CE, cUL, TUV, UL

Tubeaxial

23 dB(A)

23.13 g

0.051 lb

Polybutylene Terephthalate (PBT)

0.168 m³/min

6 CFM

40 mm

Square

40 mm

12 VDC

6000 RPM

Ball

Mechatronics Fan Group

G4015L05B2-RSR

15 mm

Locked Rotor Sensor, Thermal Overload Protector (TOP)

3 Wire Leads

CE, cUL, TUV, UL

Tubeaxial

20 dB

23.13 g

0.051 lb

Polybutylene Terephthalate (PBT)

17.4 Pa

0.07 in H2O

0.2 A

0.112 m³/min

4 CFM

40 mm

Square

40 mm

5 V

4000 RPM

Ball

Mechatronics Fan Group

G4015X12B1-RSR

15 mm

Speed Sensor (Tach), Thermal Overload Protector (TOP)

3 Wire Leads

CE, cUL, TUV, UL

Tubeaxial

39 dB(A)

23.13 g

0.051 lb

Polybutylene Terephthalate (PBT)

149.5 Pa

0.6 in H2O

0.35 A

0.336 mł/min

12 CFM

40 mm

Square

40 mm

12 VDC

12000 RPM

Ball

Part	Width [x]	Features	Termination	Approval Agency	Fan Type	Noise	Weight	Weight	Material - Blade	Static Pressure	Static Pressure	Current Rating (Amps)	Air Flow	Air Flow	Size / Dimension [z]	Size / Dimension	Size / Dimension [x]	Voltage - Rated	RPM	Bearing Type
Mechatronics Fan Group G4015H05B-RSR	15 mm	Thermal Overload Protector (TOP)	2 Wire Leads	CE, cUL, TUV, UL	Tubeaxial	29 dB(A)	23.13 g	0.051 lb	Polybutylene Terephthalate (PBT)	72.2 Pa	0.29 in H2O	400 mA	0.224 mł/min	8 CFM	40 mm	Square	40 mm	5 V	8000 RPM	Ball
Mechatronics Fan Group G4015X12B-RSR	15 mm	Thermal Overload Protector (TOP)	2 Wire Leads	CE, cUL, TUV, UL	Tubeaxial	39 dB(A)	23.13 g	0.051 lb	Polybutylene Terephthalate (PBT)	149.5 Pa	0.6 in H2O	0.35 A	0.336 mł/min	12 CFM	40 mm	Square	40 mm	12 VDC	12000 RPM	Ball
Mechatronics Fan Group G4015L24B-RSR	15 mm	Thermal Overload Protector (TOP)	2 Wire Leads	CE, cUL, TUV, UL	Tubeaxial	20 dB	23.13 g	0.051 lb	Polybutylene Terephthalate (PBT)	17.4 Pa	0.07 in H2O	50 mA	0.112 m³/min	4 CFM	40 mm	Square	40 mm	24 VDC	4000 RPM	Ball
Mechatronics Fan Group G4015H24B-RSR	15 mm	Thermal Overload Protector (TOP)	2 Wire Leads	CE, cUL, TUV, UL	Tubeaxial	29 dB(A)	23.13 g	0.051 lb	Polybutylene Terephthalate (PBT)	72.2 Pa	0.29 in H2O	0.09 A	0.224 mł/min	8 CFM	40 mm	Square	40 mm	24 VDC	8000 RPM	Ball
Mechatronics Fan Group G4015E24B-RSR	15 mm	Thermal Overload Protector (TOP)	2 Wire Leads	CE, cUL, TUV, UL	Tubeaxial	35 dB	23.13 g	0.051 lb	Polybutylene Terephthalate (PBT)	107.1 Pa	0.43 in H2O	110 mA			40 mm	Square	40 mm	24 VDC	10000 RPM	Ball
Mechatronics Fan Group G4015E12B-RSR	15 mm	Thermal Overload Protector (TOP)	2 Wire Leads	CE, cUL, TUV, UL	Tubeaxial	35 dB	23.13 g	0.051 lb	Polybutylene Terephthalate (PBT)	107.1 Pa	0.43 in H2O	270 mA	0.28 mł/min	10 CFM	40 mm	Square	40 mm	12 VDC	10000 RPM	Ball
Mechatronics Fan Group G4015X24B-RSR	15 mm	Thermal Overload Protector (TOP)	2 Wire Leads	CE, cUL, TUV, UL	Tubeaxial	39 dB(A)	23.13 g	0.051 lb	Polybutylene Terephthalate (PBT)	149.5 Pa	0.6 in H2O		0.336 mł/min	12 CFM	40 mm	Square	40 mm	24 VDC	12000 RPM	Ball
Mechatronics Fan Group G4015M12B-RSR	15 mm	Thermal Overload Protector (TOP)	2 Wire Leads	CE, cUL, TUV, UL	Tubeaxial	23 dB(A)	23.13 g	0.051 lb	Polybutylene Terephthalate (PBT)				0.168 m³/min	6 CFM	40 mm	Square	40 mm	12 VDC	6000 RPM	Ball
Mechatronics Fan Group G4015L05B2-RSR	15 mm	Locked Rotor Sensor, Thermal Overload Protector (TOP)	3 Wire Leads	CE, cUL, TUV, UL	Tubeaxial	20 dB	23.13 g	0.051 lb	Polybutylene Terephthalate (PBT)	17.4 Pa	0.07 in H2O	0.2 A	0.112 m³/min	4 CFM	40 mm	Square	40 mm	5 V	4000 RPM	Ball
Mechatronics Fan Group G4015X12B1-RSR	15 mm	Speed Sensor (Tach), Thermal Overload Protector (TOP)	3 Wire Leads	CE, cUL, TUV, UL	Tubeaxial	39 dB(A)	23.13 g	0.051 lb	Polybutylene Terephthalate (PBT)	149.5 Pa	0.6 in H2O	0.35 A	0.336 mł/min	12 CFM	40 mm	Square	40 mm	12 VDC	12000 RPM	Ball
