B25690C2367K803
ActiveEPCOS - TDK Electronics
360UF +-10% 2800V PEC MKP DC
B25690C2367K803
ActiveEPCOS - TDK Electronics
360UF +-10% 2800V PEC MKP DC
Description
General part information
B25690C2367K803
360 µF Film Capacitor 2800V (2.8kV) Radial, Can
Technical Specifications
Parameters and characteristics for this part
| Specification | B25690C2367K803 |
|---|---|
| Applications | General Purpose |
| Capacitance | 360 µF |
| ESR (Equivalent Series Resistance) | 1.3 mOhm |
| Height - Seated (Max) | 13.583 in |
| Lead Spacing | 1.969 in |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 75 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can, Radial |
| Size / Dimension Diameter | 5.354 in |
| Termination | Threaded, Female |
| Tolerance | 10 % |
| Voltage Rating - DC | 2800 V |
