2174831213

Active

PRE-CRIMPED LEAD MINI-FIT SR. MALE-TO-PIGTAIL, GOLD (AU) PLATING, 225.00MM LENGTH, 10 AWG, BLACK

Active

PRE-CRIMPED LEAD MINI-FIT SR. MALE-TO-PIGTAIL, GOLD (AU) PLATING, 225.00MM LENGTH, 10 AWG, BLACK

Description

General part information

Pre-Crimped Lead Mini-Fit Sr. Male-to-Pigtail, Gold (Au) Plating, 450.00mm Length, 8 AWG, Black

Parameters and characteristics for this part

Pre-Crimped Lead Mini-Fit Sr. Male-to-Pigtail, Gold (Au) Plating, 450.00mm Length, 8 AWG, Black

Part	Color	Contact End	Contact End Shape	Contact Finish Thickness	Contact Finish	Wire Gauge	Length	Number of Rows	Number of Conductors
Molex 2174831224	Black	Pin to Cable	Round	30 µin	Gold	8 AWG	11.8 in
Molex 2174832214	Red	Pin to Cable	Round	30 µin	Gold	10 AWG	11.8 in	1	1
Molex 2174831212	Black	Pin to Cable	Round	30 µin	Gold	10 AWG	5.91 in
Molex 2174832224	Red	Pin to Cable	Round	30 µin	Gold	8 AWG	11.8 in
Molex 2174832223	Red	Pin to Cable	Round	30 µin	Gold	8 AWG	8.86 in	1	1
Molex 2174831225	Black	Pin to Cable	Round	30 µin	Gold	8 AWG	17.7 in
Molex 2174832203	Red	Pin to Cable	Round	30 µin	Gold	12 AWG	8.86 in
Molex 2174832212	Red	Pin to Cable	Round	30 µin	Gold	10 AWG	5.91 in
Molex 2174831214	Black	Pin to Cable	Round	30 µin	Gold	10 AWG	11.8 in
Molex 2174831215	Black	Pin to Cable	Round	30 µin	Gold	10 AWG	17.7 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
