IS43TR16256BL-107MBL

Active

ISSI, Integrated Silicon Solution Inc

IC DRAM 4GBIT PAR 96TWBGA

Deep-Dive with AI

Search across all available documentation for this part.

IS43TR16256BL-107MBL

Active

ISSI, Integrated Silicon Solution Inc

IC DRAM 4GBIT PAR 96TWBGA

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	IS43TR16256BL-107MBL

Access Time	20 ns
Clock Frequency	933 MHz
Memory Format	DRAM
Memory Interface	Parallel
Memory Organization	256 M
Memory Size	512 kb
Memory Type	Volatile
Mounting Type	Surface Mount
Operating Temperature [Max]	95 °C
Operating Temperature [Min]	0 °C
Package / Case	96-TFBGA
Supplier Device Package	96-TWBGA (9x13)
Technology	SDRAM - DDR3L
Voltage - Supply [Max]	1.45 V
Voltage - Supply [Min]	1.283 V
Write Cycle Time - Word, Page	15 ns

IS43TR16256 Series

Part	Technology	Supplier Device Package	Memory Interface	Memory Format	Package / Case	Qualification	Voltage - Supply [Max]	Voltage - Supply [Min]	Access Time	Memory Type	Grade	Write Cycle Time - Word, Page	Memory Organization	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Clock Frequency	Memory Size
ISSI, Integrated Silicon Solution Inc IS43TR16256B-093NBLI-TR	SDRAM - DDR3	96-TWBGA (9x13)	Parallel	DRAM	96-TFBGA	AEC-Q100	1.575 V	1.425 V	20 ns	Volatile	Automotive	15 ns	256 M	Surface Mount	95 °C	-40 °C	1066 MHz	512 kb
ISSI, Integrated Silicon Solution Inc IS43TR16256A-15HBLI	SDRAM - DDR3	96-TWBGA (9x13)	Parallel	DRAM	96-TFBGA		1.575 V	1.425 V	20 ns	Volatile		15 ns	256 M	Surface Mount	95 °C	-40 °C	667 MHz	512 kb
ISSI, Integrated Silicon Solution Inc IS43TR16256AL-15HBLI-TR	SDRAM - DDR3L	96-TWBGA (9x13)	Parallel	DRAM	96-TFBGA		1.45 V	1.283 V	20 ns	Volatile		15 ns	256 M	Surface Mount	95 °C	-40 °C	667 MHz	512 kb
ISSI, Integrated Silicon Solution Inc IS43TR16256A-107MBLI	SDRAM - DDR3	96-TWBGA (9x13)	Parallel	DRAM	96-TFBGA		1.575 V	1.425 V	20 ns	Volatile		15 ns	256 M	Surface Mount	95 °C	-40 °C	933 MHz	512 kb
ISSI, Integrated Silicon Solution Inc IS43TR16256B-093NBLI	SDRAM - DDR3	96-TWBGA (9x13)	Parallel	DRAM	96-TFBGA	AEC-Q100	1.575 V	1.425 V	20 ns	Volatile	Automotive	15 ns	256 M	Surface Mount	95 °C	-40 °C	1066 MHz	512 kb
ISSI, Integrated Silicon Solution Inc IS43TR16256AL-107MBL	SDRAM - DDR3L	96-TWBGA (9x13)	Parallel	DRAM	96-TFBGA		1.45 V	1.283 V	20 ns	Volatile		15 ns	256 M	Surface Mount	95 °C	0 °C	933 MHz	512 kb
ISSI, Integrated Silicon Solution Inc IS43TR16256A-107MBL	SDRAM - DDR3	96-TWBGA (9x13)	Parallel	DRAM	96-TFBGA		1.575 V	1.425 V	20 ns	Volatile		15 ns	256 M	Surface Mount	95 °C	0 °C	933 MHz	512 kb
ISSI, Integrated Silicon Solution Inc IS43TR16256BL-125KBLI	SDRAM - DDR3L	96-TWBGA (9x13)	Parallel	DRAM	96-TFBGA		1.45 V	1.283 V	20 ns	Volatile		15 ns	256 M	Surface Mount	95 °C	-40 °C	800 MHz	512 kb
ISSI, Integrated Silicon Solution Inc IS43TR16256B-125KBL	SDRAM - DDR3	96-TWBGA (9x13)	Parallel	DRAM	96-TFBGA		1.575 V	1.425 V	20 ns	Volatile		15 ns	256 M	Surface Mount	95 °C	0 °C	800 MHz	512 kb
ISSI, Integrated Silicon Solution Inc IS43TR16256A-093NBL	SDRAM - DDR3	96-TWBGA (9x13)	Parallel	DRAM	96-TFBGA	AEC-Q100	1.575 V	1.425 V	20 ns	Volatile	Automotive	15 ns	256 M	Surface Mount	95 °C	0 °C	1066 MHz	512 kb

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	1	$ 11.09
		10	$ 9.85
		25	$ 9.40
		40	$ 9.17
		80	$ 8.85
		230	$ 8.37
		440	$ 8.10
		945	$ 7.78

Description

General part information

IS43TR16256 Series

SDRAM - DDR3L Memory IC 4Gbit Parallel 933 MHz 20 ns 96-TWBGA (9x13)

Documents

Technical documentation and resources

No documents available
