ATS-TECHILL-3500A
ObsoleteAdvanced Thermal Solutions Inc.
THERMOELECTRIC (TEC) BASED CHILL
ATS-TECHILL-3500A
ObsoleteAdvanced Thermal Solutions Inc.
THERMOELECTRIC (TEC) BASED CHILL
Description
General part information
ATS-TECHILL-3500A
Active, Recirculating Chiller/Heater 180 ~ 264VAC 3 kW 20 A 1GPM (3.79LPM)
Technical Specifications
Parameters and characteristics for this part
| Specification | ATS-TECHILL-3500A |
|---|---|
| Current | 20 A |
| Dimensions - Overall Height | 26.6 " |
| Dimensions - Overall Length | 15.7 " |
| Dimensions - Overall Width | 28.4 " |
| Features | Temperature Control |
| Flow Rate | 1 GPM |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | 5 °C |
| Power - Cooling | 3000 W |
| Product Type | Recirculating Chiller, Active, Heater |
| Voltage (Max) | 264 VAC |
| Voltage (Min) | 180 VAC |
