Specification	474K400CS6

Applications	Switching, DC Link, DC Filtering, High Frequency
Capacitance	0.47 µF
Dielectric Material	Metallized, Polymer
ESR (Equivalent Series Resistance)	11 mOhm
Features	Low ESL, Low ESR
Height - Seated (Max)	0.319 in
Lead Spacing	0.591 in
Mounting Type	Through Hole
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-55 °C
Package / Case	6-DIP
Size / Dimension Length	0.701 in
Size / Dimension Width	0.46 in
Termination	PC Pins
Tolerance	10 %
Voltage Rating - DC	400 V
