ZXFV202N8EV

Active

Diodes Inc

EVAL BOARD FOR ZXFV202

Search across all available documentation for this part.

Active

Diodes Inc

EVAL BOARD FOR ZXFV202

Technical Specifications

Parameters and characteristics for this part

Specification	ZXFV202N8EV

-3db Bandwidth	210 MHz
Amplifier Type	Video
Board Type	Fully Populated
Channels per IC	1 - Single
Current - Output / Channel [custom]	40 mA
Current - Supply (Main IC)	7.5 mA
Output Type	Single-Ended
Slew Rate	600 V/µs
Supplied Contents	Board(s)
Utilized IC / Part	ZXFV202
Voltage - Supply, Single/Dual (±) [Max]	5.25 V
Voltage - Supply, Single/Dual (±) [Min]	-4.75 V

Part	Amplifier Type	Voltage - Supply, Single/Dual (±) [Min]	Voltage - Supply, Single/Dual (±) [Max]	Output Type	Board Type	Current - Supply (Main IC)	Slew Rate	-3db Bandwidth	Current - Output / Channel [custom]	Supplied Contents	Utilized IC / Part	Channels per IC	Current - Supply	Supplier Device Package	Mounting Type	Package / Case	Number of Circuits
Diodes Inc ZXFV202N8EV	Video	-4.75 V	5.25 V	Single-Ended	Fully Populated	7.5 mA	600 V/µs	210 MHz	40 mA	Board(s)	ZXFV202	1 - Single
Diodes Inc ZXFV202E5TA		-4.75 V	5.25 V				600 V/µs	210 MHz	40 mA				7.5 mA	SOT-23-5	Surface Mount	SC-74A SOT-753	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	N/A	1	$ 68.85

General part information

ZXFV202 1 - Single Channels per IC Video Amplifier Evaluation Board
