Description
General part information
31107112
12 Position Terminal Block Plug for Unshrouded Header 0.197" (5.00mm) 90° Free Hanging (In-Line)
Technical Specifications
Parameters and characteristics for this part
| Specification | 31107112 |
|---|---|
| Color | Black |
| Contact Material | Copper Tin |
| Contact Mating Finish | Tin |
| Current - UL | 10 A |
| Housing Material | Nylon 6/6, Polyamide, PA66 |
| Insulation Height | 0.504 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Number of Positions | 12 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.197 in |
| Plug Wire Entry Angle | 90 ° |
| Positions Per Level | 12 |
| Screw Size | M3 |
| Termination Style | Screw - Leaf Spring, Wire Guard |
| Torque - Screw | 0.68 Nm |
| Type | Plug for Unshrouded Header |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG (Max) | 28 AWG |
| Wire Gauge or Range - AWG (Min) | 12 AWG |
| Wire Gauge or Range - mm² (Maximum) | 2.5 mm² |
| Wire Gauge or Range - mm² (Minimum) | 0.08 mm² |
