Specification	1206J1000332MXTE03

Applications	Bypass, Decoupling
Capacitance	3300 pF
Features	Low ESL (X2Y)
Height (Max)	0.051 in
Mounting Type	Surface Mount, MLCC
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-55 °C
Package / Case	1206 (3216 Metric)
Size / Dimension Length	0.126 in
Size / Dimension Width	0.063 in
Temperature Coefficient	X7R
Thickness (Max)	0.051 in
Tolerance	20 %
Voltage - Rated	100 VAC/DC

1206J Series

...

Part	Temperature Coefficient	Tolerance	Voltage - Rated	Ratings	Capacitance	Thickness (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Applications	Package / Case	Size / Dimension Width	Size / Dimension Length	Features
Knowles Syfer 1206J5000152KAT	C0G NP0 (1B)	10 %	500 V	AEC-Q200	1500 pF	0.063 in	125 °C	-55 °C	MLCC Surface Mount	Automotive	1206 (3216 Metric)	0.063 in	0.126 in
Knowles Syfer 1206J2000100KCT	C0G NP0 (1B)	10 %	200 VDC		10 pF	0.063 in	125 °C	-55 °C	MLCC Surface Mount	General Purpose	1206 (3216 Metric)	0.063 in	0.126 in
Knowles Syfer 1206J0500682JDT	X7R	5 %	50 V		6800 pF	0.063 in	125 °C	-55 °C	MLCC Surface Mount	High Reliability	1206 (3216 Metric)	0.063 in	0.126 in	High Temperature
Knowles Syfer 1206J2500390FFT	C0G NP0	1 %	250 V		39 pF	0.063 in	125 °C	-55 °C	MLCC Surface Mount	High Reliability	1206 (3216 Metric)	0.063 in	0.126 in	High Temperature
Knowles Syfer 1206J1001P80DCT	C0G NP0 (1B)	0.5 pF	100 VAC/DC		1.8 pF	0.063 in	125 °C	-55 °C	MLCC Surface Mount	General Purpose	1206 (3216 Metric)	0.063 in	0.126 in
Knowles Syfer 1206J0630101GFT	C0G NP0	2 %	63 V		100 pF	0.063 in	125 °C	-55 °C	MLCC Surface Mount	High Reliability	1206 (3216 Metric)	0.063 in	0.126 in	High Temperature
Knowles Syfer 1206J1000472MXT	X7R	20 %	100 VAC/DC		4700 pF	0.063 in	125 °C	-55 °C	MLCC Surface Mount	General Purpose	1206 (3216 Metric)	0.063 in	0.126 in
Knowles Syfer 1206J1000472JDT	X7R	5 %	100 VAC/DC		4700 pF	0.063 in	125 °C	-55 °C	MLCC Surface Mount	High Reliability	1206 (3216 Metric)	0.063 in	0.126 in	High Temperature
Knowles Syfer 1206J0500220JAT	C0G NP0 (1B)	5 %	50 V	AEC-Q200	22 pF	0.063 in	125 °C	-55 °C	MLCC Surface Mount	Automotive	1206 (3216 Metric)	0.063 in	0.126 in
Knowles Syfer 1206J2500331JXT	X7R	5 %	250 V		330 pF	0.063 in	125 °C	-55 °C	MLCC Surface Mount	General Purpose	1206 (3216 Metric)	0.063 in	0.126 in
