EVM10-40-2P
ActiveEaton - Electronics Division
AUTOMOTIVE FUSE, 40A, 500V, 10MM X 38MM ROHS COMPLIANT: YES
EVM10-40-2P
ActiveEaton - Electronics Division
AUTOMOTIVE FUSE, 40A, 500V, 10MM X 38MM ROHS COMPLIANT: YES
Description
General part information
EVM10-40-2P
40A 500 VDC Fuse Cartridge Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | EVM10-40-2P |
|---|---|
| Applications | Electrical, Industrial |
| Breaking Capacity | 20 kA |
| Current Rating | 40 A |
| DC Cold Resistance | 0.0022 Ohms |
| Fuse Type | Cartridge |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Radial Bend Cylinder |
| Size / Dimension Diameter | 0.406 in |
| Size / Dimension Length | 1.583 in |
| Voltage Rating - DC | 500 V |
