Description
General part information
PEH536VEM4100M4
1 mF 400 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In - 4 Lead 90mOhm @ 100Hz 4600 Hrs @ 105°C
Technical Specifications
Parameters and characteristics for this part
| Specification | PEH536VEM4100M4 |
|---|---|
| Applications | General Purpose |
| Capacitance | 1 mF |
| ESR (Equivalent Series Resistance) | 90 mOhm |
| Height - Seated (Max) | 3.228 in |
| Lead Spacing | 0.886 in |
| Lifetime | 4600 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package Leads | 4 Leads |
| Package Name | Radial, Can - Snap-In |
| Polarization | Polar |
| Ripple Current | 3.1 A, 19.7 A |
| Size / Dimension Diameter | 1.575 in |
| Tolerance | 20 % |
| Voltage - Rated | 400 V |
