RD25S0000X/AA

Active

POSITRONIC

CONN D-SUB HOUSING RCPT 25POS

Deep-Dive with AI

Search across all available documentation for this part.

RD25S0000X/AA

Active

POSITRONIC

CONN D-SUB HOUSING RCPT 25POS

Deep-Dive with AI

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Newark	Each	10	$ 44.90
		25	$ 43.46
		50	$ 40.80
		100	$ 38.39

Description

General part information

RD25S Series

Receptacle for Female Contacts Housing D-Sub Connector 25 Position

Documents

Technical documentation and resources

No documents available

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	RD25S0000X/AA	RD25S Series

Color	Green	Green
Connector Style	D-Sub	D-Sub
Connector Type	Receptacle for Female Contacts	Receptacle for Female Contacts, Receptacle, Female Sockets
Contact Finish	-	Gold
Contact Finish Thickness	-	Flash
Contact Material	-	Copper Alloy
Contact Type	Signal	Signal
Current Rating (Amps)	-	7.5 A
Dielectric Material	Diallyl Phthalate (DAP), Glass Filled	Diallyl Phthalate (DAP), Glass Filled
Features	-	Cable Clamp, Backshell, Mounting Hardware
Flange Feature	Housing/Shell (Unthreaded)	Housing/Shell (Unthreaded), Female Screwlock (4-40), Mating Side
Ingress Protection	IP67, IP65	IP67, IP65
Material Flammability Rating	-	UL94 V-0
Mating Cycles	1000	1000
Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
Note	Contacts Not Included	Contacts Not Included
Number of Rows	2	2
Operating Temperature [Max]	125 °C	125 °C
Operating Temperature [Min]	-55 °C	-55 °C
Shell Material, Finish	-	Stainless Steel, Passivated, Clear Chromate Plated Zinc, Steel
Shell Size, Connector Layout [custom]	DB, B	DB, B
Shell Size, Connector Layout [custom]	3	3
Termination	-	Crimp
Voltage Rating	-	300 VDC
Wire Gauge	-	20 AWG
Wire Gauge	-	24 AWG

RD25S Series

CONN D-SUB HOUSING RCPT 25POS

Part	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Shell Size, Connector Layout [custom]	Shell Size, Connector Layout [custom]	Flange Feature	Shell Material, Finish	Note	Contact Type	Mounting Type	Ingress Protection	Mating Cycles	Dielectric Material	Color	Number of Rows	Connector Style	Current Rating (Amps)	Features	Contact Material	Voltage Rating	Termination	Contact Finish	Contact Finish Thickness	Material Flammability Rating	Wire Gauge [Min]	Wire Gauge [Max]
POSITRONIC RD25S0000S	-55 °C	125 °C	Receptacle for Female Contacts	B, DB	3	Housing/Shell (Unthreaded)	Passivated, Stainless Steel	Contacts Not Included	Signal	Free Hanging (In-Line)	IP65, IP67	1000	Diallyl Phthalate (DAP), Glass Filled	Green	2	D-Sub
POSITRONIC RD25S10HTS/AA	-55 °C	125 °C	Receptacle, Female Sockets	B, DB	3	Female Screwlock (4-40), Mating Side	Passivated, Stainless Steel		Signal	Free Hanging (In-Line)	IP65, IP67		Diallyl Phthalate (DAP), Glass Filled	Green	2	D-Sub	7.5 A	Backshell, Cable Clamp, Mounting Hardware	Copper Alloy	300 VDC	Crimp	Gold	Flash	UL94 V-0	20 AWG	24 AWG
POSITRONIC RD25S0000X/AA	-55 °C	125 °C	Receptacle for Female Contacts	B, DB	3	Housing/Shell (Unthreaded)		Contacts Not Included	Signal	Free Hanging (In-Line)	IP65, IP67	1000	Diallyl Phthalate (DAP), Glass Filled	Green	2	D-Sub
POSITRONIC RD25S100T2X	-55 °C	125 °C	Receptacle, Female Sockets	B, DB	3	Female Screwlock (4-40), Mating Side			Signal	Free Hanging (In-Line)	IP65, IP67		Diallyl Phthalate (DAP), Glass Filled	Green	2	D-Sub	7.5 A		Copper Alloy	300 VDC	Crimp	Gold	Flash	UL94 V-0	20 AWG	24 AWG
POSITRONIC RD25S100V3S/AA	-55 °C	125 °C	Receptacle, Female Sockets	B, DB	3	Housing/Shell (Unthreaded)	Passivated, Stainless Steel		Signal	Free Hanging (In-Line)	IP65, IP67		Diallyl Phthalate (DAP), Glass Filled	Green	2	D-Sub	7.5 A		Copper Alloy	300 VDC	Crimp	Gold	Flash	UL94 V-0	20 AWG	24 AWG
POSITRONIC RD25S10JVL0	-55 °C	125 °C	Receptacle, Female Sockets	B, DB	3	Housing/Shell (Unthreaded)	Clear Chromate Plated Zinc, Steel		Signal	Free Hanging (In-Line)	IP65, IP67		Diallyl Phthalate (DAP), Glass Filled	Green	2	D-Sub	7.5 A	Backshell, Cable Clamp, Mounting Hardware	Copper Alloy	300 VDC	Crimp	Gold	Flash	UL94 V-0	20 AWG	24 AWG
POSITRONIC RD25S0000S/AA	-55 °C	125 °C	Receptacle for Female Contacts	B, DB	3	Housing/Shell (Unthreaded)	Passivated, Stainless Steel	Contacts Not Included	Signal	Free Hanging (In-Line)	IP65, IP67	1000	Diallyl Phthalate (DAP), Glass Filled	Green	2	D-Sub
