3404.0009.11

Active

SCHURTER Inc.

FUSE BRD MNT 1A 125VAC/VDC 2SMD

Search across all available documentation for this part.

Active

SCHURTER Inc.

FUSE BRD MNT 1A 125VAC/VDC 2SMD

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	3404.0009.11	3404.0009 Series

Breaking Capacity @ Rated Voltage	100 A	100 A
Current Rating (Amps)	1 A	1 A
Fuse Type	Board Mount	Board Mount
Melting I²t	0.078	0.078
Mounting Type	Surface Mount	Surface Mount
Operating Temperature [Max]	125 °C	125 °C
Operating Temperature [Min]	-55 °C	-55 °C
Package / Case	2-SMD, J-Lead	2-SMD, J-Lead
Response Time	Fast Blow	Fast Blow
Size / Dimension [x]	7.4 mm	7.4 mm
Size / Dimension [x]	0.291 "	0.291 "
Size / Dimension [y]	0.122 in	0.122 in
Size / Dimension [y]	3.1 mm	3.1 mm
Size / Dimension [z]	2.6 mm	2.6 mm
Size / Dimension [z]	0.102 "	0.102 "
Voltage Rating - AC	125 V	125 V
Voltage Rating - DC	125 VDC	125 VDC

FUSE CHIP FAST ACTING 1A 125V SMD SOLDER PAD 7.4 X 3.1 X 2.6MM THERMOPLASTIC T/R CULUS

Part	Melting I²t	Fuse Type	Package / Case	Mounting Type	Breaking Capacity @ Rated Voltage	Voltage Rating - AC	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Response Time	Voltage Rating - DC	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]
SCHURTER Inc. 3404.0009.24	0.078	Board Mount	2-SMD, J-Lead	Surface Mount	100 A	125 V	0.122 in	7.4 mm	2.6 mm	3.1 mm	0.291 "	0.102 "	Fast Blow	125 VDC	1 A	-55 °C	125 °C
SCHURTER Inc. 3404.0009.11	0.078	Board Mount	2-SMD, J-Lead	Surface Mount	100 A	125 V	0.122 in	7.4 mm	2.6 mm	3.1 mm	0.291 "	0.102 "	Fast Blow	125 VDC	1 A	-55 °C	125 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

1 A 125 V AC 125 V DC Fuse Board Mount (Cartridge Style Excluded) Surface Mount 2-SMD, J-Lead
