Specification	52T19B04181

Connector Type	HDMI
Contact Finish	Gold
Current Rating	0.5 A
Gender	Receptacle
Insulation Color	Black
Material Flammability Rating	UL94 V-0
Mating Cycles	10000 cycles
Mounting Feature	Horizontal
Mounting Type	Through Hole, Right Angle, Surface Mount
Number of Contacts	19
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-55 °C
Shell/Shielding Material	Copper Alloy
Shielding	Shielded
Specifications	HDMI 1.4
Termination	PC Board, Solder
Voltage - Rated	40 V
