ERM060W-1600-42

Obsolete

ERP Power, LLC

LED DRIVER CC AC/DC 32-42V 1.6A

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

ERM060W-1600-42

Obsolete

ERP Power, LLC

LED DRIVER CC AC/DC 32-42V 1.6A

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	100	$ 38.17

Description

General part information

ERM060W Series

1.6A 32 ~ 42V Constant Current LED Driver AC DC Converter Topology 1 Output

Documents

Technical documentation and resources

Datasheet

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	ERM060W-1600-42	ERM060W Series

Approval Agency	CB, cUL, FC, UL, CE, cRUcs	CB, cUL, FC, UL, CE, cRUcs
Current - Output (Max) [Max]	1.6 A	1.4 - 700 A
Dimming	Analog	Analog
Efficiency	90 %	90 %
Features	OTP, SCP, OCP	OTP, SCP, OCP
Mounting Type	Chassis Mount	Chassis Mount
Number of Outputs	1	1
Operating Temperature [Max]	90 °C	90 °C
Operating Temperature [Min]	-30 ░C	-30 ░C
Power (Watts)	67 W	57 - 70 W
Ratings	IP64	IP64
Size / Dimension [x]	3.21 "	3.21 "
Size / Dimension [x]	81.5 mm	81.5 mm
Size / Dimension [y]	2.21 in	2.21 in
Size / Dimension [y]	56.1 mm	56.1 mm
Size / Dimension [z]	32.5 mm	32.5 mm
Size / Dimension [z]	1.28 in	1.28 in
Termination Style	Wire Leads	Wire Leads
Topology	AC DC Converter	AC DC Converter
Type	Constant Current	Constant Current
Voltage - Input (Max) [Max]	277 VAC	277 VAC
Voltage - Input (Min) [Min]	120 VAC	120 VAC
Voltage - Output [Max]	42 V	40 - 82 V
Voltage - Output [Min]	32 V	30 - 62 V
Weight	0.617 lb	0.617 lb
Weight	280 g	280 g

ERM060W Series

LED DRIVER CC AC/DC 30-40V 1.75A

Part	Operating Temperature [Min]	Operating Temperature [Max]	Termination Style	Features	Dimming	Weight	Weight	Mounting Type	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Type	Approval Agency	Power (Watts)	Ratings	Voltage - Output [Min]	Voltage - Output [Max]	Voltage - Input (Max) [Max]	Efficiency	Number of Outputs	Voltage - Input (Min) [Min]	Current - Output (Max) [Max]	Topology
ERP Power, LLC ERM060W-1750-40	-30 ░C	90 °C	Wire Leads	OCP, OTP, SCP	Analog	0.617 lb	280 g	Chassis Mount	32.5 mm	2.21 in	3.21 "	1.28 in	56.1 mm	81.5 mm	Constant Current	CB, CE, cRUcs, cUL, FC, UL	70 W	IP64	30 V	40 V	277 VAC	90 %	1	120 VAC	1.75 A	AC DC Converter
ERP Power, LLC ERM060W-0700-82	-30 ░C	90 °C	Wire Leads	OCP, OTP, SCP	Analog	0.617 lb	280 g	Chassis Mount	32.5 mm	2.21 in	3.21 "	1.28 in	56.1 mm	81.5 mm	Constant Current	CB, CE, cRUcs, cUL, FC, UL	57 W	IP64	62 V	82 V	277 VAC	90 %	1	120 VAC	700 mA	AC DC Converter
ERP Power, LLC ERM060W-1400-42	-30 ░C	90 °C	Wire Leads	OCP, OTP, SCP	Analog	0.617 lb	280 g	Chassis Mount	32.5 mm	2.21 in	3.21 "	1.28 in	56.1 mm	81.5 mm	Constant Current	CB, CE, cRUcs, cUL, FC, UL	59 W	IP64	32 V	42 V	277 VAC	90 %	1	120 VAC	1.4 A	AC DC Converter
ERP Power, LLC ERM060W-1600-42	-30 ░C	90 °C	Wire Leads	OCP, OTP, SCP	Analog	0.617 lb	280 g	Chassis Mount	32.5 mm	2.21 in	3.21 "	1.28 in	56.1 mm	81.5 mm	Constant Current	CB, CE, cRUcs, cUL, FC, UL	67 W	IP64	32 V	42 V	277 VAC	90 %	1	120 VAC	1.6 A	AC DC Converter
ERP Power, LLC ERM060W-2100-28	-30 ░C	90 °C	Wire Leads	OCP, OTP, SCP	Analog	0.617 lb	280 g	Chassis Mount	32.5 mm	2.21 in	3.21 "	1.28 in	56.1 mm	81.5 mm	Constant Current	CB, CE, cRUcs, cUL, FC, UL	59 W	IP64			277 VAC	90 %	1	120 VAC	2.1 A	AC DC Converter
