Description
General part information
VQA3-S24-D15-S
Isolated Module DC DC Converter 2 Output 15V -9V 100mA, 100mA 21.6V - 26.4V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | VQA3-S24-D15-S |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | cURus |
| Current - Output (Max) Options | 100mA |
| Efficiency | 82 % |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package Leads | 5 Leads |
| Package Name | 7-SIP |
| Size / Dimension Height | 0.49 in |
| Size / Dimension Length | 0.77 in |
| Size / Dimension Width | 0.39 in |
| Standard Number | 62368-1 |
| Type | Isolated Module |
| Voltage - Input (Max) | 26.4 V |
| Voltage - Input (Min) | 21.6 V |
| Voltage - Isolation | 5.6 kV |
| Voltage - Output 1 | 15 V |
| Voltage - Output 2 | -9 V |
